Ecler ic8

DescriptionIC8 2-way loudspeaker is the perfect option for 70/100 V and low impedance sound solutions. It mounts an 8 woofer and a 1" tweeter in a discreet design. IC series provide excellent sound quality thanks to their infinite baffle philosophy and a top-performance high frequency transducer.
Features2 way speaker for false ceilings
8 polypropylene woofer
25mm tweeter
Power: 60W RMS @ 8 ohm
Sensitivity (1W/1m): 94 dB SPL
Built-in transformer
External diameter: 245mm
Cut out diameter: 222mm
Available in white (RAL9010) finish
Installation system: Three revolving fasteners
Applications
Retail   Corporate   Leisure   Sports & Wellness   Hospitality

SpecsSYSTEM
Effective Freq. Range
65 Hz-20 kHz (-10dB)
Coverage angle / Dispersion
135°
Power handling
60 W RMS / 240 W Peak
Sensitivity
94 dB (1W/1m)
Maximum SPL
112 dB continuous / 118 dB peak
Power options (Hi Z Multi-tap)
100V: 30W / 15W / 7,5W / 5W / 8
70V: 15W / 7,5W / 3,75W / 2,5W / 8
Recommended amplifier power
120 W RMS
TRANSDUCERS
Ways
2-ways full range
Low frequency driver
8" woofer
High frequency driver
1" tweeter
Nominal impedance
8
PHYSICAL
Connection type
Clip-type input terminals
Installation options
In-ceiling, in-wall
Enclosure material
ABS
Grille material
Aluminium rust proof
Mounting system
3 rotating tabs
Operating temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity
<85% HR
Storage temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity
<90% HR
External diameter
245 mm / 9.64"
Internal diameter
219 mm / 8.62"
Recommended cut out diameter
222 mm / 8.74"
Required depth
91 mm / 3.58"
Ceiling thickness
5mm / 0.19 min
20mm / 0.78 max

Included accessories
Cutting and painting templates included
Finished colour
White (RAL 9010)
Weight
2.3 kg / 5.07 lb
Pieces per box
2 units
Shipping dimensions
290 x 290 x 260 mm / 11.41 x 11.41 x 10.23 in. (WxHxD)
Shipping weight
2.60 kg / 5.73 lb
